This project was a part of my grad school homework, in which we were taught how to implement various resource-locking algorithms to protect shared memory resources in a concurrent programming environment.
I have implemented total of 7 algorithms, namely: tas lock, ttas lock, ticket lock, mcs lock, peterson lock with sequential consistency, peterson lock with released consistency and sense reversal barrier. Apart from these algorithms, I have also used mutex lock and barrier<> available in the C++ library.
Description of Algorithms
1. TAS Lock
The Test-and-Set (TAS) lock is implemented using Compare-and-Swap (CAS) algorithm, as C++ doesn’t have its own TAS implementation. The TAS lock atomically checks if the lock is currently acquired by polling a flag. If value of the flag is currently true, that means the lock is currently acquired and a call to CAS returns false. In such a way, the thread keeps on polling the flag until and unless the thread itself sets the value of flag to true, atomically. To achieve this, the TAS lock continuously tries to acquire the lock, by spinning. Once the thread sets the flag to true, it is considered that the thread has acquired the lock. The TAS class exports two methods, TAS::TAS_lock() which acquires the lock, and TAS::TAS_unlock() which releases the lock. While releasing the lock, the thread simply sets the value of flag to false, notifying other threads that the lock is now free to be acquired. TAS lock is a LIFO lock, which means that the thread which just released the lock has high chances of re-acquiring the lock, which may result into starvation. Thus, TAS lock is an unfair locking scheme.
2. TTAS Lock
The Test-and-Test-and-Set (TTAS) lock is also implemented using Compare-and-Swap (CAS) algorithm. TTAS lock is very similar to TAS lock. Every attempt to acquire a TAS lock while waiting causes a coherent transition, and chances of cache miss are high. Hence, in TTAS lock, we only attempt to acquire the lock when it is not held. The TTAS lock, similar to TAS lock, keeps on polling a flag to check whether the lock is currently held or not. However, the only difference is that instead of constantly trying to acquire the lock, TTAS lock waits patiently till the flag is released by other threads, and only then makes an attempt to acquire the lock. This reduces the chances of cache misses. The TTAS class exports two methods, TTAS::TTAS_lock() which acquires the lock, and TTAS::TTAS_unlock() which releases the lock.Similar to TAS lock, TTAS lock is also a LIFO lock, which means that the thread which just released the lock has high chances of re-acquiring the lock, which may result into starvation. Thus, TTAS lock is also an unfair locking scheme.
3. Ticket Lock
The Ticket Lock is implemented using two variables, now_serving & next_num. The idea is to create a waiting queue of threads by assigining each thread a ‘ticket’ number to acquire the lock and access the resource. Every time a thread wishes to acquire the lock, it will be assigned a number my_num, and then the thread will keep waiting until now_serving == my_num. As soon as the number assigned to thread equals the value of now_serving, it is considered as the thread has acquired the lock. To achieve this, we use Fetch-and-Increment (FAI) method, which atomically increments the value of a variable by 1. The TicketLock class exports two methods, TicketLock::Ticket_lock(), which acquires the lock, and TicketLock::Ticket_unlock(), which releases the lock. To release the lock, the thread simply increments the value of now_serving by 1 atomically, so that next thread waiting in line will get a chance to acquire the lock. Ticket lock is a FIFO lock, which means that if a thread waits long enough, it will eventually get a chance to acqire the lock. Thus, each thread gets equal chance of acquiring the lock, making Ticket lock a fair locking scheme.
4. MCS Lock
The Mellor-Crummey-Scott (MCS) lock is implemented using a queue for waiting threads. On arrival, we place a node in the queue by appending the node to the queue. The idea is that instead of polling continuously on a global variable (like TAS, TTAS and Ticket locks), we spin on a local node until eventually it’s our turn to acquire the lock. The MCS class exports two methods, MCS::acquire() which acquires the lock, and MCS::release() which releases the lock. Upon arrival, we notify our predecessor thread of our presence and desire to acquire the lock after the previous thread is done. While releasing the lock, we check if there is any successor waiting to acquire the lock. If yes, then we notify the next thread that the lock is available, otherwise, we release the lock and queue becomes empty. MCS lock is a FIFO lock, which means that if a thread waits long enough, it will eventually get a chance to acqire the lock. Thus, each thread gets equal chance of acquiring the lock, making MCS lock a fair locking scheme.
5. Peterson’s lock with Sequential & Released consistency
The Peterson’s algorithm for locking is the simplest method of writing a lock using only two threads. If a thread desires to acquire the lock, we notify the system, but first we give other thread a chance to acquire the lock. Then, we wait until the other thread loses the desire to acquire the lock, or it is our turn to acquire the lock. The Peterson lock exports 4 methods, Peterson::sequential_lock(), which acquires the lock strictly with sequential memory consistency, Peterson::sequential_unlock() which releases the lock which was acquired with sequential consistency, Peterson::released_lock() which acquires the lock with a mixture of sequential and released memory consistency, and Peterson::released_unlock() which releases the lock acquired by Peterson::released_lock(). While releasing the lock, we simply notify notify the system that our turn is over, atomically.
6. Sense Reversal Barrier
Sense Reversal Barrier is a barrier which flips its sense every iteration. Barrier is a synchronization method for threads in which threads keep waiting at a barrier untill all threads have arrived, and then all the threads are released together for further execution. The idea is that every time a thread arrives at a barrier, it will flip its own sense, and will keep waiting for all threads to arrive. The last thread to arrive will flip its own sense, along with the global sense of the entire barrier, at which point all threads are notified that the barrier has released the threads. This algorithm is a centralized barrier implementation, which has high contention. The Barrier class exports only one method, Barrier::wait() which acts as a barrier for all threads.
Discussion of Performance
I used the perf tool to test the performance of each of the lock designed on two applications. First application was a simple benchmarking counter program which simply increments a global counter using multiple threads. Second application was the Bucket Sort algorithm which was used to sort a large data set of numbers in ascending order, using multiple threads.
For Counter
All algorithms were tested with 4 threads for 1000000 iterations (except Peterson’s algorithm, which was tested with 2 threads only).
| Algorithm | Runtime (s) | L1-Cache Hit (%) | Branch Prediction Hit (%) | Page Faults | Context Switches |
|---|---|---|---|---|---|
| TAS Lock | 0.389392 | 87.14 | 99.52 | 148 | 25 |
| TTAS Lock | 0.522926 | 98.76 | 99.44 | 147 | 19 |
| Ticket Lock | 1.255164 | 99.56 | 99.93 | 145 | 39 |
| MCS Lock | 0.602592 | 99.27 | 99.86 | 147 | 25 |
| Peterson Seq Lock | 0.293019 | 98.25 | 99.66 | 139 | 06 |
| Peterson Rel Lock | 0.599347 | 100 | 100 | 138 | 10 |
| Pthread Lock | 0.179125 | 97.25 | 99.27 | 148 | 5470 |
| Sense Reversal Barrier | 2.688599 | 99.1 | 99.38 | 151 | 22 |
| Pthread Barrier | 159.004761 | 92.31 | 96.81 | 145 | 17797744 |
For Bucket Sort
All algorithms were tested with 4 threads with a skewed data set of 550000 inputs (except Peterson’s algorithm, which was tested with 2 threads only).
| Lock | Barrier | Runtime (s) | L1-Cache Hit (%) | Branch Prediction Hit (%) | Page Faults | Context Switches |
|---|---|---|---|---|---|---|
| TAS Lock | Sense Reversal Barrier | 0.373841 | 98.17 | 99.04 | 8064 | 10 |
| TTAS Lock | Sense Reversal Barrier | 0.217075 | 98.92 | 99.07 | 8070 | 08 |
| Ticket Lock | Sense Reversal Barrier | 0.286948 | 99.24 | 99.39 | 8071 | 11 |
| MCS Lock | Sense Reversal Barrier | 0.386161 | 99.13 | 99.57 | 8067 | 27 |
| Peterson Seq Lock | Sense Reversal Barrier | 0.240243 | 98.89 | 99.12 | 8059 | 03 |
| Peterson Rel Lock | Sense Reversal Barrier | 0.360756 | 98.96 | 99.34 | 8058 | 09 |
| Pthread Lock | Sense Reversal Barrier | 0.57843 | 98.40 | 98.76 | 8070 | 22466 |
| TAS Lock | Pthread Barrier | 0.22065 | 97.75 | 98.00 | 8067 | 17 |
| TTAS Lock | Pthread Barrier | 0.284703 | 98.72 | 99.06 | 8064 | 24 |
| Ticket Lock | Pthread Barrier | 0.293001 | 99.16 | 99.42 | 8064 | 13 |
| MCS Lock | Pthread Barrier | 0.320619 | 99.26 | 99.46 | 8062 | 29 |
| Peterson Seq Lock | Pthread Barrier | 0.24754 | 99.12 | 99.20 | 8054 | 07 |
| Peterson Rel Lock | Pthread Barrier | 0.245768 | 99.03 | 99.16 | 8060 | 23 |
| Pthread Lock | Pthread Barrier | 0.683298 | 96.78 | 97.94 | 8065 | 37414 |
Observations & Analysis
By looking at the data, we can conclude that the cache hit rate for TAS lock is significantly poor than other locking algorithms. This is because the TAS lock continuously tries to acquire the lock even when the lock is currently being acquired, which causes cache misses. While attempting to acquire, the TAS lock continuously tries to write to the memory, but fails. While it attempts to write, all the copies of memory are invalidated and only one modifiable copy of cache line is created. Since the thread fails to write to the memory, the compiler again creates new copies. This keeps happening until the lock is acquired. This can cause a ping-pong reaction between two cores for a single cache line, leading to more cache misses. To tackle this, we use TTAS lock, which has better performance results than TAS lock, which only tries to acquire the lock when the lock is not being held. TAS and TTAS are LIFO locks, which means that the thread which just relesed the lock has high chances of re-acquiring the lock. Therefore, context switches for TAS and TTAS locks are relatively lower than other FIFO locks. Ticket lock is a FIFO lock, hence it has higher context switches than TAS and TTAS lock. Every time a thread relases the ticket lock, a cache miss occurs. By releasing a lock, the thread writes to the memory atomically, thereby invalidating all copies of cache lines. Hence, all other waiting threads undergo a cache miss when lock is released. MCS lock is also a FIFO lock and thus its context switches are higher than other LIFO locks. MCS lock uses a local node to spin, instead of a global node, and thus performs significantly consistent in all scenarios. Peterson lock with sequential consistency behaves poorly in terms of cache hits and branch prediction because compiler takes strict actions to ensure sequential execution of intended program. This impacts the peformance of cache and branch prediction. On the other hand, released consistency is not as strict, and thus it improves cache hits and branch prediction rates. Pthread locks are robust and implemented using various complex algorithms, and evidently it has extremely high number of context switches. Even though it is the fastest one to complete counter application, it is the slowest locking method to complete bucketsort application. Furthermore, cache hit rate and branch prediction rate for pthreads is relatively poor than other locking algorithms. Sense reversal barrier has less context switches and performs much better than pthread lock in both cases. The execution of the program can get really slow when the cores available on the system are limited. For very fair primitives or benchmarks, this can be a huge performance problem. In the counter application’s barrier version, for each iteration of the thread, one thread increments the counter and others wait. In order to complete the iteration and continue to the next one, each thread must arrive at the barrier. Now, if we have only 2 cores, threads 1 & 2 will run through the iteration and then have to wait to be descheduled for threads 3&4 to reach the barrier. This keeps on happening because the resources are limited, and the entire execution gets really slow. Similarly, in fair locking schemes such as ticket lock and mcs lock where a thread enters the queue for a lock, then gets descehduled, and their turn arrives while they were descheduled. In this scenario, no other thread can acquire the lock for that time slice. Pthread barrier behaves very poorly in either cases because of exceedingly high number of context switches. The CPU spends most of its time in context switches and has really less time to perform the execution at hand. This impacts the speed, as well as cache hit and branch prediction rate.
This project can be downloaded and run on any machine that runs Linux operating system. The source code for this project is open.
Source Code: Link
